The H800 is an extremely high-detail monocular inspection microscope with a 0.7X to 5X zoom range. Mounted on a heavy-duty double-arm stand, this microscope is the ideal tool for inspection applications. The included LED ring-light offers even, cool illumination. The 1080p 60fps camera provides crystal-clear, stutter-free video for live monitoring and recording via the HDMI interface. Attach it directly to a monitor or television, and use the built-in software for turnkey video inspection. Attach it to a PC via its USB 2.0 interface, and use the included software to record still images and video up to 30fps.

Features:

0.7X-5.0X zoom objective

C-mount lens

Long working distance

Sharp images over a super wide field view

Large Metal stand and framework



Specifications :

Zoom microscope objective: 0.7X-5.0X

Mount: 0.4X C-mount

Working distance: 4-1/8" (105mm)

Stand is 30" Overall Length

20" Double Arms

17" High Pillar

10-1/4" x 8-1/4" x 2-0" Solid Cast Steel Base

Color: black



Camera Specifications:

Sensor: Sony IMX236 CMOS

Sensor Size: 1/2.8"

Preview and Capture Resolution: 3264x1840 (SD Card),  3264x1840, 1920x1080 (PC)

Video Resolution: 1920x1080

Live Frame Rate: 60fps @ 1920x1080 via HDMI, 30fps @ 1920x1080 via USB2.0 & SD Card Slot Recording

Recording Frame Rate: 30fps @ 1920x1080

Image Storage: SD Card Slot

Scan Mode: Progressive

Exposure Time: 0.001 sec ~ 10.0 sec

White Balance: Auto

Settings: Gain, Gamma, Saturation, Cotraction

Screen Built-in Software: Cloud 1.0

PC Software: ISCapture

Interfaces: USB2.0, HDMI

Compatibility: Windows XP/7/8 (32/64 bit)

Optical Port: Standard C-mount

Power Supply: DC 12V / 2A

Dimensions: 78mm x 70.8mm x 90.7mm



Built-in Software Features

- Captures Still Images & Records Video

- 1080p Video Recording (30 fps)

- Auto Exposure & Manual Exposure Setting Options

- Saturation, Brightness, Contrast, & Tint Options

- Auto White Balance Functionality

- 3D Noise Reduction

- ROI Magnification Functions (Image Flip, Rotation, ROI)

- Image Side by Side Comparison Functionality

- Built-in File Browser

- Lifetime software updates



Computer Software Features

- Compatible with Windows XP/Vista/7/8 (32 & 64 bit) & Mac OS X 10.6.8+

- Computer Requirements: CPU Equivalent to Intel Core2 2.8GHz or higher, Memory: 2GB or more, USB2.0 port

- Preview live images right on your computer

- Record images and video (30 fps record rate over USB2.0)

- Auto and manual control of exposure, gain, white balance, gamma, contrast, saturation, and more

- Lifetime software updates



Packing List :

One Monocular Zoom Microscope Head with 0.7-5.0X Objective and 0.4X C-Mount Lens

One Focusing Rack

One Double-arm Heavy-duty Stand

One Dust Cover

One 96-LED ring-light

One Control Unite for Light

One AC Adapter for Light

One 1080P Digital Camera

One USB Mouse

One HDMI Cable

One USB Cable

One Software CD

One AC Adapter for Camera



AmScope H800-DAB-96S-HD1080
