Accu-Scope EXC-121 Monocular Microscope
Superb optics and student-proof design (eyepieces, objectives and viewing heads are locked-in) make the 3088F Series a best in class choice in the educational market. A robust, variable, rechargeable LED illuminator or 5 watt fluorescent illuminator provides bright, white light allowing for rich contrast on slide samples. Configurations are availabe with disc or iris diaphragms, mechanical stages and/or teaching heads. - See more at: http://accu-scope.com/monocular-microscopes
The Accu-Scope EXC-121 is a best in class high quality monocular microscope loaded with student friendly features. The 10x W.F. eyepieces locks into place to prevent tampering. The rackless mechanical stage eliminates any moving parts from sticking out the side of the stage platform. The built in carry handle makes transporting the microscope easy and safe, and the built in cord wrap allows for neat and tidy storage. The microscope can come with either 4x, 10x, 40x objectives or 4x, 10x, 40x, and 100x Oil objectives. This comes in monocular, or monocular with vertical camera port. The vertical camera port can allow two people to view through the microscope at one by adding another eyepiece, or be used to add a camera. The LED illumination eliminates the need to replace bulbs and provides smooth even illumination.
| Microscope Specifications: | |
|---|---|
| Head: |
Monocular, inclined 35°, rotatable 360° or Monocular w/ vertical photo port inclined 35°, rotatable 360° |
| Eyepiece: | WF10x eyepiece, 18.5mm field of view with pointer; eyepieces are locked-in to prevent classroom tampering |
| Nosepiece: | Reversed quadruple nosepiece |
| Objectives: | DIN Plan Achromat 4x, 10x, 40x or 4x, 10x, 40x, 100x Oil |
| Condenser: | 1.25 N.A. Condenser w/ Iris |
| Stage: | Rackless XY Mechanical Stage |
| Illumination: | Variable LED Illumination |
| Focusing: | Coaxial Coarse & Fine Focus |
| Accessories: | Dust cover, cord wrap, & instruction manual included |
| Warranty: | 5 Year Mechanical & Electrical, 1 year warranty on LED bulb |
Accessories
Achromat / Semi-Plan Objectives
Brochure
Accu-Scope EXC-120 BrochureSuperb optics and student-proof design (eyepieces, objectives and viewing heads are locked-in) make the 3088F Series a best in class choice in the educational market. A robust, variable, rechargeable LED illuminator or 5 watt fluorescent illuminator provides bright, white light allowing for rich contrast on slide samples. Configurations are availabe with disc or iris diaphragms, mechanical stages and/or teaching heads. - See more at: http://accu-scope.com/monocular-microscopes
The Accu-Scope EXC-121 is a best in class high quality monocular microscope loaded with student friendly features. The 10x W.F. eyepieces locks into place to prevent tampering. The rackless mechanical stage eliminates any moving parts from sticking out the side of the stage platform. The built in carry handle makes transporting the microscope easy and safe, and the built in cord wrap allows for neat and tidy storage. The microscope can come with either 4x, 10x, 40x objectives or 4x, 10x, 40x, and 100x Oil objectives. This comes in monocular, or monocular with vertical camera port. The vertical camera port can allow two people to view through the microscope at one by adding another eyepiece, or be used to add a camera. The LED illumination eliminates the need to replace bulbs and provides smooth even illumination.
| Microscope Specifications: | |
|---|---|
| Head: |
Monocular, inclined 35°, rotatable 360° or Monocular w/ vertical photo port inclined 35°, rotatable 360° |
| Eyepiece: | WF10x eyepiece, 18.5mm field of view with pointer; eyepieces are locked-in to prevent classroom tampering |
| Nosepiece: | Reversed quadruple nosepiece |
| Objectives: | DIN Plan Achromat 4x, 10x, 40x or 4x, 10x, 40x, 100x Oil |
| Condenser: | 1.25 N.A. Condenser w/ Iris |
| Stage: | Rackless XY Mechanical Stage |
| Illumination: | Variable LED Illumination |
| Focusing: | Coaxial Coarse & Fine Focus |
| Accessories: | Dust cover, cord wrap, & instruction manual included |
| Warranty: | 5 Year Mechanical & Electrical, 1 year warranty on LED bulb |
Accessories
Achromat / Semi-Plan Objectives
Brochure
Description
Superb optics and student-proof design (eyepieces, objectives and viewing heads are locked-in) make the 3088F Series a best in class choice in the educational market. A robust, variable, rechargeable LED illuminator or 5 watt fluorescent illuminator provides bright, white light allowing for rich contrast on slide samples. Configurations are availabe with disc or iris diaphragms, mechanical stages and/or teaching heads. - See more at: http://accu-scope.com/monocular-microscopes
The Accu-Scope EXC-121 is a best in class high quality monocular microscope loaded with student friendly features. The 10x W.F. eyepieces locks into place to prevent tampering. The rackless mechanical stage eliminates any moving parts from sticking out the side of the stage platform. The built in carry handle makes transporting the microscope easy and safe, and the built in cord wrap allows for neat and tidy storage. The microscope can come with either 4x, 10x, 40x objectives or 4x, 10x, 40x, and 100x Oil objectives. This comes in monocular, or monocular with vertical camera port. The vertical camera port can allow two people to view through the microscope at one by adding another eyepiece, or be used to add a camera. The LED illumination eliminates the need to replace bulbs and provides smooth even illumination.
| Microscope Specifications: | |
|---|---|
| Head: |
Monocular, inclined 35°, rotatable 360° or Monocular w/ vertical photo port inclined 35°, rotatable 360° |
| Eyepiece: | WF10x eyepiece, 18.5mm field of view with pointer; eyepieces are locked-in to prevent classroom tampering |
| Nosepiece: | Reversed quadruple nosepiece |
| Objectives: | DIN Plan Achromat 4x, 10x, 40x or 4x, 10x, 40x, 100x Oil |
| Condenser: | 1.25 N.A. Condenser w/ Iris |
| Stage: | Rackless XY Mechanical Stage |
| Illumination: | Variable LED Illumination |
| Focusing: | Coaxial Coarse & Fine Focus |
| Accessories: | Dust cover, cord wrap, & instruction manual included |
| Warranty: | 5 Year Mechanical & Electrical, 1 year warranty on LED bulb |
Accessories
Achromat / Semi-Plan Objectives
