.Lumenera 2-1R 1.4 Megapixel CCD Digital Camera Series

Product image 1

.Lumenera 2-1R 1.4 Megapixel CCD Digital Camera Series

INFINITY2-1R — 1.4 Megapixel CCD Color USB 2.0 Camera

Industry's Best Price-to-Performance Uncooled ICX205 Camera! 2-1R scientific camera offers a significant performance increase for quantitative and low-light applications over its predecessor. Improved thermal management techniques combined with a much higher dynamic range and 14-bit output have resulted in a versatile entry-level research camera for documentation and image analysis in Life Science, Clinical and Material Science applications. The INFINITY2-1R easily manages seconds of exposure time with a dark current rating of less than 1 e-/s.

The INFINITY2-1R has a dynamic range of 64 dB allowing users to image unevenly lit samples without worry. The resulting images show detail in bright and dark areas not normally seen in lower dynamic range cameras. Advanced thermal management allows for long exposure times of several minutes without the need for a much higher priced cooled camera.

INFINITY CAPTURE, an intuitive image capture program, and INFINITY ANALYZE, a full image analysis package offering; camera control, measurement, annotation, tiling and post capture enhancement, are both included. Camera and software combined to create a complete microscopy imaging solution for your application.

Product Highlights:

  • Improved noise performance over first generation camera
  • Incredibly low dark current noise in an uncooled camera
  • High dynamic range of 64 dB
  • Low noise progressive scan 1/2" 1.4 megapixel Sony ICX205 CCD sensor
  • Selectable 8 or 14-bit pixel data modes

    Technical Specifications:

    Camera Sensor
    Image Sensor: ½” Interline Sony ICX205 1.4 megapixel color or monochrome progressive scan CCD sensor 7.6 x 6.2mm array
    Effective Pixels: 1392 x 1040, 4.65 µm square pixels
    Frame Rate: 30 fps at 1392 x 1040, 52 fps at 640 x 480 (ROI)
    Dynamic Range: 64.6 dB
    Digital Output: 8 or 14-bit
    Read Noise: 8.5 e-
    Dark Current Noise: < 1 e-/s at 22 °C
    Dimensions (W x H x D): 2.25 x 3.85 x 1.56 inch (enclosed)
    57.15 x 97.79 x 39.624 mm
    Camera Controls
    Mass: 340 g
    Power Requirement: USB bus power (external 5 V DC, 500 mA)
    Power Consumption: ~2.5 W
    Operating Temperature: 0 to +50 °C
    Operating Humidity: 5 to 95 %, non-condensing
    Exposure Range: 48 ÎĽs to 500 ms (video), 5.4 ÎĽs to 8 min (snapshot)
    Shutter: Electronic global shutter
    Region of Interest: Any multiple of 8 x 8 pixels, 120 x 120 pixels
    minimum
    Exposure Control: Manual and automatic
    White Balance: Manual and automatic
    Gain Range: 0.5 to 15 x
    Interface Connector: Standard USB 2.0 high-speed interface
    Sensitivity: 2.5 DN/(nJ/cm2) [at 8-bit, 1 x gains]
    Full Well Capacity: 14,500 e-
    Lens Mount: Adjustable C-mount standard

    Software compatible with Windows 8, 7, XP, Vista, Mac OS X 10.7, 32 and 64-bit operating systems.

    INFINITY2-1R — 1.4 Megapixel CCD Color USB 2.0 Camera

    Industry's Best Price-to-Performance Uncooled ICX205 Camera! 2-1R scientific camera offers a significant performance increase for quantitative and low-light applications over its predecessor. Improved thermal management techniques combined with a much higher dynamic range and 14-bit output have resulted in a versatile entry-level research camera for documentation and image analysis in Life Science, Clinical and Material Science applications. The INFINITY2-1R easily manages seconds of exposure time with a dark current rating of less than 1 e-/s.

    The INFINITY2-1R has a dynamic range of 64 dB allowing users to image unevenly lit samples without worry. The resulting images show detail in bright and dark areas not normally seen in lower dynamic range cameras. Advanced thermal management allows for long exposure times of several minutes without the need for a much higher priced cooled camera.

    INFINITY CAPTURE, an intuitive image capture program, and INFINITY ANALYZE, a full image analysis package offering; camera control, measurement, annotation, tiling and post capture enhancement, are both included. Camera and software combined to create a complete microscopy imaging solution for your application.

    Product Highlights:

    • Improved noise performance over first generation camera
    • Incredibly low dark current noise in an uncooled camera
    • High dynamic range of 64 dB
    • Low noise progressive scan 1/2" 1.4 megapixel Sony ICX205 CCD sensor
    • Selectable 8 or 14-bit pixel data modes

      Technical Specifications:

      Camera Sensor
      Image Sensor: ½” Interline Sony ICX205 1.4 megapixel color or monochrome progressive scan CCD sensor 7.6 x 6.2mm array
      Effective Pixels: 1392 x 1040, 4.65 µm square pixels
      Frame Rate: 30 fps at 1392 x 1040, 52 fps at 640 x 480 (ROI)
      Dynamic Range: 64.6 dB
      Digital Output: 8 or 14-bit
      Read Noise: 8.5 e-
      Dark Current Noise: < 1 e-/s at 22 °C
      Dimensions (W x H x D): 2.25 x 3.85 x 1.56 inch (enclosed)
      57.15 x 97.79 x 39.624 mm
      Camera Controls
      Mass: 340 g
      Power Requirement: USB bus power (external 5 V DC, 500 mA)
      Power Consumption: ~2.5 W
      Operating Temperature: 0 to +50 °C
      Operating Humidity: 5 to 95 %, non-condensing
      Exposure Range: 48 ÎĽs to 500 ms (video), 5.4 ÎĽs to 8 min (snapshot)
      Shutter: Electronic global shutter
      Region of Interest: Any multiple of 8 x 8 pixels, 120 x 120 pixels
      minimum
      Exposure Control: Manual and automatic
      White Balance: Manual and automatic
      Gain Range: 0.5 to 15 x
      Interface Connector: Standard USB 2.0 high-speed interface
      Sensitivity: 2.5 DN/(nJ/cm2) [at 8-bit, 1 x gains]
      Full Well Capacity: 14,500 e-
      Lens Mount: Adjustable C-mount standard

      Software compatible with Windows 8, 7, XP, Vista, Mac OS X 10.7, 32 and 64-bit operating systems.

      Select Title
      From $727.50

      Original: $2,425.00

      -70%
      .Lumenera 2-1R 1.4 Megapixel CCD Digital Camera Series—

      $2,425.00

      $727.50

      Description

      INFINITY2-1R — 1.4 Megapixel CCD Color USB 2.0 Camera

      Industry's Best Price-to-Performance Uncooled ICX205 Camera! 2-1R scientific camera offers a significant performance increase for quantitative and low-light applications over its predecessor. Improved thermal management techniques combined with a much higher dynamic range and 14-bit output have resulted in a versatile entry-level research camera for documentation and image analysis in Life Science, Clinical and Material Science applications. The INFINITY2-1R easily manages seconds of exposure time with a dark current rating of less than 1 e-/s.

      The INFINITY2-1R has a dynamic range of 64 dB allowing users to image unevenly lit samples without worry. The resulting images show detail in bright and dark areas not normally seen in lower dynamic range cameras. Advanced thermal management allows for long exposure times of several minutes without the need for a much higher priced cooled camera.

      INFINITY CAPTURE, an intuitive image capture program, and INFINITY ANALYZE, a full image analysis package offering; camera control, measurement, annotation, tiling and post capture enhancement, are both included. Camera and software combined to create a complete microscopy imaging solution for your application.

      Product Highlights:

      • Improved noise performance over first generation camera
      • Incredibly low dark current noise in an uncooled camera
      • High dynamic range of 64 dB
      • Low noise progressive scan 1/2" 1.4 megapixel Sony ICX205 CCD sensor
      • Selectable 8 or 14-bit pixel data modes

        Technical Specifications:

        Camera Sensor
        Image Sensor: ½” Interline Sony ICX205 1.4 megapixel color or monochrome progressive scan CCD sensor 7.6 x 6.2mm array
        Effective Pixels: 1392 x 1040, 4.65 µm square pixels
        Frame Rate: 30 fps at 1392 x 1040, 52 fps at 640 x 480 (ROI)
        Dynamic Range: 64.6 dB
        Digital Output: 8 or 14-bit
        Read Noise: 8.5 e-
        Dark Current Noise: < 1 e-/s at 22 °C
        Dimensions (W x H x D): 2.25 x 3.85 x 1.56 inch (enclosed)
        57.15 x 97.79 x 39.624 mm
        Camera Controls
        Mass: 340 g
        Power Requirement: USB bus power (external 5 V DC, 500 mA)
        Power Consumption: ~2.5 W
        Operating Temperature: 0 to +50 °C
        Operating Humidity: 5 to 95 %, non-condensing
        Exposure Range: 48 ÎĽs to 500 ms (video), 5.4 ÎĽs to 8 min (snapshot)
        Shutter: Electronic global shutter
        Region of Interest: Any multiple of 8 x 8 pixels, 120 x 120 pixels
        minimum
        Exposure Control: Manual and automatic
        White Balance: Manual and automatic
        Gain Range: 0.5 to 15 x
        Interface Connector: Standard USB 2.0 high-speed interface
        Sensitivity: 2.5 DN/(nJ/cm2) [at 8-bit, 1 x gains]
        Full Well Capacity: 14,500 e-
        Lens Mount: Adjustable C-mount standard

        Software compatible with Windows 8, 7, XP, Vista, Mac OS X 10.7, 32 and 64-bit operating systems.
