The Motic AE2000 inverted phase contrast microscope is a popular routine inverted microscope for tissue culture applications. This microscope is available in a binocular version or trinocular so that you can add a camera. The microscope comes standard with 10x eyepieces. We offer this in two package options for the objectives. The Basic Package includes Plan Achromat Phase Contrast 4x, and 10x objectives. The PH20x Package includes Plan Achromat Phase Contrast 4x, 10x, and 20x objectives. Both packages include the corresponding phase contrast slider and plain stage with metal and glass inserts. If desired an optional mechanical stage can be added to this microscope.

Not sure which camera to add? Ask our experts and we can help!



Specifications
Head:	Binocular Siedentopf 45° inclined OR Trinocular Siedentopf 45° inclined (Light Split: 20/80)
Eyepieces:	Widefield high eyepoint eyepiece 10X / 20mm (paired), focusable
Nosepiece:	Side facing quadruple nosepiece
Objectives:	Basic Package - CCIS Plan Achromat PL PH4x, PH10x PH20x Package - CCIS Plan Achromat PL PH4x, PH10x, PH20x
Condenser:	ELWD N.A. 0.30 condenser - Phase slider Ph0, BF, Ph1
Stage:	Plain Stage with metal & glass stage inserts
Illumination:	3W LED with intensity control Universal Power Supply 100-240V
Focusing:	Coaxial focusing system with an adjustable tension control and upper limit stop to prevent accidental damage to slides; all metal gears, brass fine focus gear
Accessories:	45mm blue, Green Interference and Diffusion filters with filter slider Centering Telescope Allen hexagonal key, vinyl dust cover, power cord
Warranty:	5 Year Mechanical &  1 Year Electrical

Accessories

• Eyepieces

• Plan Achromatic Objectives

• Plan Achromatic Phase Objectives

• C-Mount Adapters

• Cameras

• Mechanical Stage

Please Contact Us for all additional parts and accessories
