Accu-Scope EXM-150-DF Darkfield Student Microscope Series

Product image 1
1 / 5

Accu-Scope EXM-150-DF Darkfield Student Microscope Series

The Accu-Scope EXM-150-DF Darkfield Student Microscope Series is a top-selling option for middle and high school students. This innovative microscope utilizes darkfield technology to reveal the unseen, making learning more engaging. When observing transparent, unstained specimens, important details can be hard to see, but with the included darkfield stop, these details become visible. Darkfield requires an adjustable iris diaphragm and is only effective at low magnifications (4x & 10x). This package includes a limited number of versions of the EXM-150 model to choose from, which meets these requirements.

  • EXM-150-MS-DF:

Monocular Viewing Head - 10x Eyepiece - 4x, 10x, 40x Objectives - Mechanical Stage

  • EXM-150-MST-DF

Dual Viewing Head - 10x Eyepiece(s) - 4x, 10x, 40x, Objectives  Mechanical Stage

  • EXM-150-I-DF

Monocular Viewing Head - 10x Eyepiece - 4x, 10x, 40x Objectives - Stage Clips

  • EXM-150-IT-DF:

Dual Viewing Head - 10x Eyepiece(s) - 4x, 10x, 40x, Objectives - Stage Clips

  • EXM-151-DF:

Monocular Viewing Head - 10x Eyepiece - 4x, 10x, 40x, 100x Oil Objectives - Mechanical Stage

  • EXM-151-T-DF:

Dual Viewing Head - 10x Eyepiece - 4x, 10x, 40x, 100x Oil Objectives - Mechanical Stage



All versions of the EXM-150-DF have student friendly features such as:

          • Carry Handle
          • Built-In Cord Wrap
          • Reversed Style Nosepiece
          • Rechargeable LED Illumination

 Easily turn the Accu-Scope EXM-150 into a digital microscope with this 3.0 M.P. eyepiece camera.

Student Microscope Specifications
Head:

Monocular, inclined 45°, rotatable 360°

or

Dual Viewing (All SKU's That include a T)
Eyepiece: WF10x eyepiece(s), 18mm field of view with pointer; eyepieces are locked-in to prevent classroom tampering
Nosepiece:

Rear facing three-hole, ball-bearing nosepiece with positive click stops to ensure parcentration.

(4 Position for models: EXM-151 Models)
Objectives:

 DIN achromat 4x, 10x and 40xR* objectives

(100x Oil Included in: EXM-151 Models)

Darkfield can only be ovserved with 4x & 10x objectives
Condenser:

N.A. 1.25 Abbe Condenser on spiral mount with iris diaphragm

Darkfield Stop
Stage:

119mm x 119mm with stage clips

OR

Factory-installed double-plate mechanical stage with low position controls and iris diaphragm. Included with all models with MS.
Illumination: Variable and rechargeable LED illuminator; LED illuminators will last approximately 4 hours on a single charge and the expected bulb life is 20,000 hours
Focusing: Separate coarse and fine focus adjustment controls; a tension adjustment is on the coarse control; a built-in slip clutch system and pre-set focus stop prevents accidental damage to objectives and slides
Accessories: Dust cover, cord wrap, & instruction manual included
Warranty: 5 Year Mechanical & Electrical, 1 year warranty on LED bulb



Accessories

    Please Contact Us for all additional parts and accessories

    Brochure

    Accu-Scope EXM-150 Brochure
