Motic BA210 Digital Compound Microscope
The BA210 Digital is a Digital version of the BA210 that features a built-in imaging head with 3.0MP streaming live output through USB2.0 connections.
| Specifications | |
|---|---|
| Head: | Binocular head Siedentopf type, 30º inclined with Built-in digital camera CMOS 1/2” chip |
| Eyepieces: | Wide field high eyepoint eyepiece N-WF10X / 20mm with diopter adjustment on both eyepieces, with rubber eyecup (paired) |
| Nosepiece: | Reversed, quadruple |
| Objectives: | CCIS EF-N Plan Achromat EF-N PL 4x, 10x, 40x S, 100x S-oil |
| Condenser: | Focusable Abbe condenser N.A. 1.25 with iris diaphragm and slot |
| Stage: | Built in low position coaxial mechanical stage (Right-hand control) |
| Illumination: |
Built in halogen illumination 6V/30W with intensity control Switching Power Supply 100V-240V |
| Focusing: | Coaxial coarse and fine focusing adjustment |
| Accessories: | 45mm blue filter, immersion oil (5ml), power cord, allen hexagonal key, vinyl dust cover |
| Camera: |
Built-in Digital Live Hi-Res Imaging Chip- 2048x 1536 Resolution USB2.0 Motic Images Plus 2.0 for PC and MAC & Calibration Slide |
| Warranty: | 5 Year Mechanical & 1 Year Electrical |
