The ACCU-CAM 500 color microscopy camera provides an affordable imaging solution for a variety of applications.  Simply replace an eyepiece with this small camera, connect to a PC, and you are viewing microscopy images like never before.  Our AccuView software provides full control of the camera for viewing, acquisition, image processing and measurement.  We support both Windows and MacOS operating systems.

 Control the ACCU-CAM with our FREE AccuView software and stream live video to the PC at an amazing 26fps.  Use our AccuView Lite software for a more streamlined experience and both Windows and MacOS compatibility.

Please Note: This camera will fit all standard monocular & binocular compound microscopes that accept a standard 23.2mm eyepiece. If you have a 30mm eyetube please select "With adapter."

ACCU-CAM 500 (AU-500-EP)
Sensor	1/2.8" Sony IMX335 color CMOS, 2.0µm pixels
Mega Pixels	5.1
Dynamic/Static Resolution	2592 x 1944
Frame Rate	29fps @ full frame (2592×1944)
Image Capture	Image saved to PC via USB2.0
Exposure	Automatic and Manual (set Exposure Time)
White Balance	Automatic and Manual
Other Settings	Gain, Gamma, Color Adjustment, Histogram
PC Imaging Software	ACCU-VIEW Imaging Software for Windows and MacOS Advanced Camera Controls: live/still image measurement and annotation; flat field correction; extended depth of focus (focus stacking); image stitching (requires mechanical stage) Image Types: TIF, JPG, PNG Video Types: MJPEG TWAIN and DirectShow plugins available
Output Mode	USB2.0
System Requirements	Intel Core 2, 2.8GHz or higher; 16GB RAM or more; USB 2.0 Hi-Speed port or higher Windows 7, 8, 10, 11 (64-bit recommended); Mac OS 10.4 or higher
Power Supply	via USB2.0
Lens Mount	Eyepiece adapter (camera fits 23.2mm I.D. eye tube or photo tube. Optional adapter (CAT #5036) available for 30mm I.D. eyepieces
