Accu-Scope EXC-400 Dermatology MOHS Surgery Microscope
This pathology grade microscope from Accu-Scope is ergonomically designed, and suitable to withstand heavy use, while providing high resolution images. A trinocular head is standard, and for added ergonomics you can upgrade to a tilting binocular head. The 10x focusing eyepieces provide a 22mm field of view and come with roll down eyeguards for added viewing comfort. A reversed quintuple nosepiece and can accept up to five objectives and has a slot for to insert an analyzer. The EXC-400 offers optical brilliance coming standard with Infinity Plan Achromatic 2x, 4x, 10x, 20, you can add an optional 40x objective. The rackless XY-mechanical stage is ergonomically positioned with tension adjustment to effortlessly move your specimen with precision. You can remove the slide holder for freehand use. The low-position of the XY-stage stalk, and coarse / fine focus knobs make using this microscope easy and comfortable to use. A 1.25 N.A. achromatic flip top condenser is supplied for use with the 2x objective lens. The LED variable illuminator provides over 20,000 hours of use and has a field iris diaphragm for koehler illumination. The Accu-Scope EXC-400 clinical microscope can upgraded to come with a high speed camera, or dual viewing attachment.
| Specifications | |
|---|---|
| Head: |
Trinocular viewing head, inclined 30°, rotatable 360°, 50/50 light split Or Ergonomic Tilting Head 5° to 35° |
| Eyepieces: | WF10x/22mm focusing eyepieces with eyeguards |
| Nosepiece: | Reversed quintuple nosepiece, with slot |
| Objectives: | Infinity Plan Achromat 2x, 4x, 10x, 20x - Optional 40x Objectives |
| Condenser: | N.A. 1.25 Swing Out Achromatic with iris diaphragm |
| Stage: | Rackless w/ adjustable tension |
| Focusing: | Coaxial low position ergonomic coarse & fine focus |
| Illumination: | 3 Watt Variable LED w/ field iris for koehler illumination |
| Accessories: | Dust cover, power cord, manual |
| Warranty: | 5 Year Mechanical & Electrical |
Accessories
Brochure
This pathology grade microscope from Accu-Scope is ergonomically designed, and suitable to withstand heavy use, while providing high resolution images. A trinocular head is standard, and for added ergonomics you can upgrade to a tilting binocular head. The 10x focusing eyepieces provide a 22mm field of view and come with roll down eyeguards for added viewing comfort. A reversed quintuple nosepiece and can accept up to five objectives and has a slot for to insert an analyzer. The EXC-400 offers optical brilliance coming standard with Infinity Plan Achromatic 2x, 4x, 10x, 20, you can add an optional 40x objective. The rackless XY-mechanical stage is ergonomically positioned with tension adjustment to effortlessly move your specimen with precision. You can remove the slide holder for freehand use. The low-position of the XY-stage stalk, and coarse / fine focus knobs make using this microscope easy and comfortable to use. A 1.25 N.A. achromatic flip top condenser is supplied for use with the 2x objective lens. The LED variable illuminator provides over 20,000 hours of use and has a field iris diaphragm for koehler illumination. The Accu-Scope EXC-400 clinical microscope can upgraded to come with a high speed camera, or dual viewing attachment.
| Specifications | |
|---|---|
| Head: |
Trinocular viewing head, inclined 30°, rotatable 360°, 50/50 light split Or Ergonomic Tilting Head 5° to 35° |
| Eyepieces: | WF10x/22mm focusing eyepieces with eyeguards |
| Nosepiece: | Reversed quintuple nosepiece, with slot |
| Objectives: | Infinity Plan Achromat 2x, 4x, 10x, 20x - Optional 40x Objectives |
| Condenser: | N.A. 1.25 Swing Out Achromatic with iris diaphragm |
| Stage: | Rackless w/ adjustable tension |
| Focusing: | Coaxial low position ergonomic coarse & fine focus |
| Illumination: | 3 Watt Variable LED w/ field iris for koehler illumination |
| Accessories: | Dust cover, power cord, manual |
| Warranty: | 5 Year Mechanical & Electrical |
Accessories
Brochure
Original: $4,063.00
-70%$4,063.00
$1,218.90Description
This pathology grade microscope from Accu-Scope is ergonomically designed, and suitable to withstand heavy use, while providing high resolution images. A trinocular head is standard, and for added ergonomics you can upgrade to a tilting binocular head. The 10x focusing eyepieces provide a 22mm field of view and come with roll down eyeguards for added viewing comfort. A reversed quintuple nosepiece and can accept up to five objectives and has a slot for to insert an analyzer. The EXC-400 offers optical brilliance coming standard with Infinity Plan Achromatic 2x, 4x, 10x, 20, you can add an optional 40x objective. The rackless XY-mechanical stage is ergonomically positioned with tension adjustment to effortlessly move your specimen with precision. You can remove the slide holder for freehand use. The low-position of the XY-stage stalk, and coarse / fine focus knobs make using this microscope easy and comfortable to use. A 1.25 N.A. achromatic flip top condenser is supplied for use with the 2x objective lens. The LED variable illuminator provides over 20,000 hours of use and has a field iris diaphragm for koehler illumination. The Accu-Scope EXC-400 clinical microscope can upgraded to come with a high speed camera, or dual viewing attachment.
| Specifications | |
|---|---|
| Head: |
Trinocular viewing head, inclined 30°, rotatable 360°, 50/50 light split Or Ergonomic Tilting Head 5° to 35° |
| Eyepieces: | WF10x/22mm focusing eyepieces with eyeguards |
| Nosepiece: | Reversed quintuple nosepiece, with slot |
| Objectives: | Infinity Plan Achromat 2x, 4x, 10x, 20x - Optional 40x Objectives |
| Condenser: | N.A. 1.25 Swing Out Achromatic with iris diaphragm |
| Stage: | Rackless w/ adjustable tension |
| Focusing: | Coaxial low position ergonomic coarse & fine focus |
| Illumination: | 3 Watt Variable LED w/ field iris for koehler illumination |
| Accessories: | Dust cover, power cord, manual |
| Warranty: | 5 Year Mechanical & Electrical |
