Accu-Scope EXC-400 Dual Viewing Pathology Microscope
This dual viewing side-by-side clinical microscope from Accu-Scope is ergonomically designed, and suitable to withstand heavy use, while providing high resolution images. You can choose between a trinocular, or ergonomic tilting binouclar head for the primary viewing head. A binocular head is provided for the secondary viewing head. The side-by-side bridge has a built in LED pointer. The 10x focusing eyepieces provide a 22mm (20mm for secondary head) field of view, and come with roll down eyeguards for added viewing comfort. A reversed quintupleĀ nosepiece andĀ can accept up to five objectives, and has a slot for to insert an analyzer. Configured for pahtology this microscope comes with 2x, 4x, 10x, 20x objectives and you can add on a 40x if needed. A ceramic coated rackless XY-mechanical stage allows your slide to move effortlessly with precision. The low-position of the XY-stage stalk, and coarse / fine focusĀ knobs make using this microscope easy and comfortable to use. A 1.25 N.A. achromatic flip top condenser allows for the use of theĀ 2x objective.Ā The LED variable illuminator provides over 20,000 hours of use, and has a field iris diaphragm for koehler illumination. Watch the demo product video in the tab above to see why the Accu-Scope EXC-400 microscope is the best microscope for your lab today!
Ā
| Specifications | |
|---|---|
| Main Head: |
TrinocularĀ viewing head, inclined 30Ā°, rotatable 360Ā°, 50/50 light splitĀ Ā Or ļ»æļ»æErgonomic Tilting HeadĀ 5Ā° to 35Ā° |
| Secondary Head: | Binocular (Can Upgrade To Ergo) |
| Dual Bridge: | Side-By-Side w/ LED Pointer |
| Eyepieces: |
WF10x/22mm focusing eyepieces with eyeguards - Primary Head WF10x/20mm focusing eyepieces with eyeguards - Secondary Head |
| Nosepiece: | Reversed quintuple nosepiece, with slot |
| Objectives: |
Infinity Plan Achromat 2, 4x, 10x, 20x Add Optional 40x Objective |
| Condenser: | N.A. 1.2 Swing Out Achromatic with iris diaphragm |
| Stage: | Large XY Stage w/ Telescoping ControlsĀ |
| Focusing: | Coaxial low position ergonomic coarse & fine focus |
| Illumination: | 3 Watt Variable LED w/ field iris for koehler illumination |
| Accessories: | Dust cover, power cord, manual |
| Warranty: | 5 Year Mechanical & Electrical |
Accessories
Product Video
Brochure
This dual viewing side-by-side clinical microscope from Accu-Scope is ergonomically designed, and suitable to withstand heavy use, while providing high resolution images. You can choose between a trinocular, or ergonomic tilting binouclar head for the primary viewing head. A binocular head is provided for the secondary viewing head. The side-by-side bridge has a built in LED pointer. The 10x focusing eyepieces provide a 22mm (20mm for secondary head) field of view, and come with roll down eyeguards for added viewing comfort. A reversed quintupleĀ nosepiece andĀ can accept up to five objectives, and has a slot for to insert an analyzer. Configured for pahtology this microscope comes with 2x, 4x, 10x, 20x objectives and you can add on a 40x if needed. A ceramic coated rackless XY-mechanical stage allows your slide to move effortlessly with precision. The low-position of the XY-stage stalk, and coarse / fine focusĀ knobs make using this microscope easy and comfortable to use. A 1.25 N.A. achromatic flip top condenser allows for the use of theĀ 2x objective.Ā The LED variable illuminator provides over 20,000 hours of use, and has a field iris diaphragm for koehler illumination. Watch the demo product video in the tab above to see why the Accu-Scope EXC-400 microscope is the best microscope for your lab today!
Ā
| Specifications | |
|---|---|
| Main Head: |
TrinocularĀ viewing head, inclined 30Ā°, rotatable 360Ā°, 50/50 light splitĀ Ā Or ļ»æļ»æErgonomic Tilting HeadĀ 5Ā° to 35Ā° |
| Secondary Head: | Binocular (Can Upgrade To Ergo) |
| Dual Bridge: | Side-By-Side w/ LED Pointer |
| Eyepieces: |
WF10x/22mm focusing eyepieces with eyeguards - Primary Head WF10x/20mm focusing eyepieces with eyeguards - Secondary Head |
| Nosepiece: | Reversed quintuple nosepiece, with slot |
| Objectives: |
Infinity Plan Achromat 2, 4x, 10x, 20x Add Optional 40x Objective |
| Condenser: | N.A. 1.2 Swing Out Achromatic with iris diaphragm |
| Stage: | Large XY Stage w/ Telescoping ControlsĀ |
| Focusing: | Coaxial low position ergonomic coarse & fine focus |
| Illumination: | 3 Watt Variable LED w/ field iris for koehler illumination |
| Accessories: | Dust cover, power cord, manual |
| Warranty: | 5 Year Mechanical & Electrical |
Accessories
Product Video
Brochure
Original: $9,980.00
-70%$9,980.00
$2,994.00Description
