Accu-Scope 3012 Hematology Microscope
The Accu-Scope 3012 Hematology Microscope is designed to meet the demand of laboratory use. You can choose between a binocular, ergonomic binocular, or trinocular viewing head. The 10x eyepieces are focusable and provide a 22mm field of view which allows you to view more of your specimen. The quintuple nosepiece comes with infinity plan achromat 10x, 40x, 50x oil and 100x oil objective lenses.The hard coated rackless mechanical XY stage has no protruding parts and is designed to withstand heavy use. The 1.25 N.A. condenser is fully focusable and has an iris diaphragm and filter holder. The 5 Watt LED variable illumination system provides over 20,000 hours of use.
|
Specifications: |
|
|
Head: |
Binocular - 30⁰ inclined and rotatable 360⁰ Ergo Tilting Binocular - 5⁰ to 30⁰ inclination range Trinocular - 50/50 Light Split, 30⁰ inclined and rotatable 360⁰ |
|
Eyepieces: |
HWF10x/22mm focusing eyepieces with eyeguards |
|
Nosepiece: |
Reversed, quintuple |
|
Objectives: |
AIS E Plan Achromat Infinity 10x, 40x 50x Oil , and 100x Oil Objectives
|
|
Stage: |
Rackless hard coated mechanical stage w/ low position coaxial controls |
|
Condenser: |
Abbe condenser, N.A. 1.25 with iris diaphragm & filter holder |
|
Focusing: |
Coaxial coarse and fine focus controls |
|
Illumination: |
5 watt variable LED illuminator. LED bulb has a rated life of 20,000 hours. Universal power supply 110-220v |
|
Accessories: |
Dust cover, immersion oil, & instruction manual |
|
Warranty: |
5 Year Mechanical & Electrical |
Accessories
Brochure
The Accu-Scope 3012 Hematology Microscope is designed to meet the demand of laboratory use. You can choose between a binocular, ergonomic binocular, or trinocular viewing head. The 10x eyepieces are focusable and provide a 22mm field of view which allows you to view more of your specimen. The quintuple nosepiece comes with infinity plan achromat 10x, 40x, 50x oil and 100x oil objective lenses.The hard coated rackless mechanical XY stage has no protruding parts and is designed to withstand heavy use. The 1.25 N.A. condenser is fully focusable and has an iris diaphragm and filter holder. The 5 Watt LED variable illumination system provides over 20,000 hours of use.
|
Specifications: |
|
|
Head: |
Binocular - 30⁰ inclined and rotatable 360⁰ Ergo Tilting Binocular - 5⁰ to 30⁰ inclination range Trinocular - 50/50 Light Split, 30⁰ inclined and rotatable 360⁰ |
|
Eyepieces: |
HWF10x/22mm focusing eyepieces with eyeguards |
|
Nosepiece: |
Reversed, quintuple |
|
Objectives: |
AIS E Plan Achromat Infinity 10x, 40x 50x Oil , and 100x Oil Objectives
|
|
Stage: |
Rackless hard coated mechanical stage w/ low position coaxial controls |
|
Condenser: |
Abbe condenser, N.A. 1.25 with iris diaphragm & filter holder |
|
Focusing: |
Coaxial coarse and fine focus controls |
|
Illumination: |
5 watt variable LED illuminator. LED bulb has a rated life of 20,000 hours. Universal power supply 110-220v |
|
Accessories: |
Dust cover, immersion oil, & instruction manual |
|
Warranty: |
5 Year Mechanical & Electrical |
Accessories
Brochure
Original: $1,980.00
-70%$1,980.00
$594.00Description
The Accu-Scope 3012 Hematology Microscope is designed to meet the demand of laboratory use. You can choose between a binocular, ergonomic binocular, or trinocular viewing head. The 10x eyepieces are focusable and provide a 22mm field of view which allows you to view more of your specimen. The quintuple nosepiece comes with infinity plan achromat 10x, 40x, 50x oil and 100x oil objective lenses.The hard coated rackless mechanical XY stage has no protruding parts and is designed to withstand heavy use. The 1.25 N.A. condenser is fully focusable and has an iris diaphragm and filter holder. The 5 Watt LED variable illumination system provides over 20,000 hours of use.
|
Specifications: |
|
|
Head: |
Binocular - 30⁰ inclined and rotatable 360⁰ Ergo Tilting Binocular - 5⁰ to 30⁰ inclination range Trinocular - 50/50 Light Split, 30⁰ inclined and rotatable 360⁰ |
|
Eyepieces: |
HWF10x/22mm focusing eyepieces with eyeguards |
|
Nosepiece: |
Reversed, quintuple |
|
Objectives: |
AIS E Plan Achromat Infinity 10x, 40x 50x Oil , and 100x Oil Objectives
|
|
Stage: |
Rackless hard coated mechanical stage w/ low position coaxial controls |
|
Condenser: |
Abbe condenser, N.A. 1.25 with iris diaphragm & filter holder |
|
Focusing: |
Coaxial coarse and fine focus controls |
|
Illumination: |
5 watt variable LED illuminator. LED bulb has a rated life of 20,000 hours. Universal power supply 110-220v |
|
Accessories: |
Dust cover, immersion oil, & instruction manual |
|
Warranty: |
5 Year Mechanical & Electrical |
